Stainless steel manifolds

The stainless steel heating manifolds from Watts are designed for radiant heating and cooling systems. Manifolds are available for 2 to 12 heating circuits; extensions for individual circuits are also available. All models comply with DIN EN 1264.

Suitable manifold accessories can be found in the category Manifold and radiant heating accessories.

Control units are available in the category Control units and mixing valves for underfloor heating and cooling.

Heating circuit manifold for 2 to 12 heating circuits
Max. operating pressure: 10 bar at 60 °C (suitable for building applications)
Operating temperature: -10 to 80 °C
Supply: lockable flow meter with low pressure loss
Flow meter display: 0–4 l/min or 0–6 l/min, depending on model
Return: regulating valves with M30 × 1.5 connection for actuators
Heating circuit connection (underfloor heating): G ¾" Euro cone
Connection with flat seals on both sides: 1" or 1¼" external thread

Heating Circuit Manifold HKV2013AFC with automatic flow control

Stainless Steel Manifold with automatic flow control HKV2013A-AFC

manifold hkf2013af

manifold hkf2013af

Stainless Steel Manifold HKV2013AF with Flow Meters for Underfloor Heating

manifold hkv2013a eskfe90

manifold hkv2013a eskfe90

Stainless Steel Manifold HKV2013AF with flow meters and end sets KFE90

manifold hkf2013af plus

manifold hkf2013af plus

Stainless Steel Manifold HKV2013AF+ with Flow Meters for Underfloor Heating equipped with end set and ball valve set

manifold hkv2013a va 1point25

Stainless steel manifold HKV2013A 1¼"

manifold hkv2010 va

Stainless Steel Manifold HKV2010-VA for Underfloor Heating

manifold hkv2010 va accessories

Stainless Steel Manifold HKV2010-VA for Underfloor Heating equipped with accessories

heating manifold extension hkve2013 ni

Heating manifold extension HKVE2013 Ni

manifold extension hkve2013a 1 0 4 ni

Heating manifold extension HKVE2013A-1-0-4-Ni
