High Protection anti-vandalism and inviolability mixing valve ULTRAMIX HP
Description
The thermostatic mixing valve ULTRAMIX "HP" has the same characteristics than the ULTRAMIX, it is equipped with anti-vandalism safety device. Mixing valve specifically conceived for the collective applications where the risks of deterioration are high. - The mechanism and its adjustment are protected by a metal frontage made inviolable by a specific high protection lock , chrome plated finish. - Anti-scalding feature and comfort : if there is not enough cold or hot water the mixing valve shuts off automatically and instantaneously. - Dismountable thermostatic mechanism equipped with filters and check valves NF. - Adjustment temperature range : 10/50°C, for thermal disinfection : 30/70°C (on request). - Rinsing kit included. Replacement cartridges below.
Technical Features
Part no.
| Flow rate (l/min) | Diameter | Points of use* | surface finish | Part no. WIF | Wieght | |
| mini 5 - maxi 56 | M 3/4” | 20x27 | 1 - 7 | high protection locking | 22T/X91CHP | 2,6 kg |
| mini 5 - maxi 80 | M 3/4” | 20x27 | 1 - 10 | high protection locking | 22T/X92CHP | 2,6 kg |
| mini 5 - maxi 120 | M 1” | 26x34 | 1 - 15 | high protection locking | 22T/X93CHP | 3,7 kg |
| mini 5 - maxi 175 | M 1”1/4 | 33x42 | 1 - 21 | high protection locking | 22T/X94CHP | 5,3 kg |
| mini 8 - maxi 260 | M 1”1/2 | 40x49 | 1 - 32 | high protection locking | 22T/X95CHP | 8,7 kg |
| mini 8 - maxi 400 | M 2” | 50x60 | 1 - 50 | high protection locking | 22T/X96CHP | 10,8 kg |
* As an indication - take into account the number of water points connected to the same network and used simultaneously.
