RF Water Heating Controller Heat & Cool WFC-03 HC
Beschrijving
The wireless Connecting box WFC-03 HC RF is especially designed to control your Under Floor Heating and Cooling system. It allows easy and quick connection of thermostats and actuators. It has integrated multiple functions: - Wall mounted or mounter on DIN Rail - Push-in cable connections with strain relief - LED status indication and DIP switch for device setting - Manage 6 or 10 zones with 2 actuators per zone - Easy merging of the zones on the same thermostat - Multiple systems configuration - H&C input (230V and volt free signal) - Water temperature measurement (Probe not supplied) for humidity detection - Pump or boiler output (230V and volt free signal) - Anti-Grip management - Overheating security - Internal RF antenna, optional external antenna - Work with NC and NO actuators - USB connectivity for software update and data log
- Electrical protection: Class II with functional earth
- IP Protection: IP30
- Shipping and storage temperature: -10°C à 50°C (14°F à 122°F)
- Power supply: 230 Vac ± 10% 50Hz
- Output maximum load (2 outputs): Relay : 5A
- Actuators: 230V /24V NC/NO up to 2.5W
- Compatibility: BT-A02 RF / BT-A03 RF; BT-D02 RF / BT-D03 RF; BT-DP02 RF / BT-DP03 RF; BT-HCM02 RF / WFHC HCM 02 RF 230; BT-CT02 RF
Technical Features
Artikelnummer
| Type | Part no. | Description |
| WFC-03 6Z 02 HC RF868 230 | P08397 | RF 6 Zones Water Heating Controller Heat & Cool 230 VAC |
| WFC-03 10Z 02 HC RF868 230 | P08399 | RF 10 Zones Water Heating Controller Heat & Cool 230 VAC |
